| Technical data | BM 350 XM-ANT ACD BASIC | BM 375 XM-ANT ACD BASIC | WM 350 XM-ANT ACD BASIC | WM 375 XM-ANT ACD BASIC |
|---|---|---|---|---|
| Material To Vacuum | Dust and liquids | Dust and liquids | Dust and liquids | Dust and liquids |
| Motorization | Nr 3 Collector motor | Nr 3 Collector motor | Nr 3 Collector motor | Nr 3 Collector motor |
| Marking | ACD | ACD | ACD | ACD |
| Power | 3300 W | 3300 W | 3300 W | 3300 W |
| Voltage | 230 V | 230 V | 230 V | 230 V |
| Frequency | 50 / 60 Hz | 50 / 60 Hz | 50 / 60 Hz | 50 / 60 Hz |
| Amperage | 14,4 A | 14,4 A | 14,4 A | 14,4 A |
| Airflow | 510 m3/h | 510 m3/h | 510 m3/h | 510 m3/h |
| Depression | 230 mBar | 230 mBar | 230 mBar | 230 mBar |
| Max Depression | - | - | - | - |
| Suction inlet | Type B Tang. 60 mm | Type B Tang. 60 mm | Type C Cent. 70 mm | Type C Cent. 70 mm |
| Dimensions | 80x60 h143 cm | 80x60 h152 cm | 80x60 h142 cm | 80x60 h152 cm |
| Weight | 67 | 67 | 67 | 67 |
| Collection System | Barrel | Barrel | Barrel | Barrel |
| Collection Capacity | 50 L | 75 L | 50 L | 75 L |
| Longopac | No | No | No | No |
| Electric Floater | - | - | - | Optional |
| Filter Chamber Diameter | Ø 460mm | Ø 460mm | Ø 460mm | Ø 460mm |
| Filter Type | Star Polyester | Star Polyester | Star Polyester | Star Polyester |
| Filtering Media And Properties | M Antistatic | L Antistatic | M Antistatic | L Antistatic |
| Filter Surface | 30.000 cm2 | 30.000 cm2 | 30.000 cm2 | 30.000 cm2 |
| Filter Cleaning | Manual Shaking | Manual Shaking | Manual Shaking | Manual Shaking |
| Filter HEPA | H13 99,95% MPPS 0,12 µm | H13 99,95% MPPS 0,12 µm | H13 99,95% MPPS 0,12 µm | H13 99,95% MPPS 0,12 µm |
